Manual CMM Coordinate Measuring Machine with Renishaw MH20I

Usage

CMM-find series Manual Coordinate Measuring machine is widely used in the field of machinery, automobile, aviation, mould, metal and high-precision tool manufacturing, which can inspect the geometric dimension, shape and position of the box, guide rail, gear, curve, cam and other work-pieces. This machine is necessary for CAD, CAE and CAM in reverse engineering.

Features & Advantage
1. Monolithic granite table, unilateral moving bridge structure, optimize the movement performance and ensure the stability and precision of the mechanical systems
2. Three axes use the 000 level high-precision nature granite guides, so three-axis has the same temperature characteristics, good rigidity and anti-aging deformation
3. All guides use high-precision air bearings, with pre-press design and no abrasion, run more smoothly and ensure excellent dynamic performance of the machine
4. Z-axis pneumatic balance design to improve motion features
5. Adopt the RENISHAW self-adhesive strip of metal reflection grating scale, so that three axes have the same coefficient of expansion and enhance the stability of the equipment
6. Adopt the high-precision RENISHAW MH20I probe
7. Adopt the JMC high quality air filter and regulator from Japan, which ensure that the machine can be used long-term stability
8. Powerful CMM software RationalDMIS provides the perfect solution for measurement, friendly interface, easy to learn and use.

Specification

Model		Find564	Find785	Find7105	Find7155
Travel (mm)	X	500	700	700	700
	Y	600	800	1000	1500
	Z	400	500	500	500
Driving System		Manual
Count System		RENISHAW scale with 0.5µm
Probing System		RENISHAW MH20I or MCP
Measuring Software		RationalDMIS
Structure		Sliding Bridge Type
Guide		Air Bearing
Accuracy (µm)		MPEE = ( 3 + L/250 )		MPEE = ( 4 + L/200 )
Max. load (kg)		300		500

Environment

Power Supply	220 V ± 10% 50/60 Hz
Air Consumption	120L/min at 0.4 MPa
Air Supply	³ 0.5 MPa
Temperature	18℃~ 22℃
Humidity	40 % ~ 70 %
